APLV Series

Low-voltage hybrid microinverter

APLV Series

On-grid, off-grid & PV charging in one platform

The APLV series combines grid-tied output, independent off-grid output, PV battery charging and scheduled AC reverse charging. Its DAB dual full-bridge topology, full isolation and 16–60 V MPPT range support flexible residential, balcony and distributed energy designs from 400 W to 4,000 W.

Select Model

Output

400 W

PV Input

1 × 500 W

MPPT / Input Range

16–60 V

Max Input Current

17.3 A

Input Short-circuit Current

—

Download Documents

Platform Capabilities

Key Features

  • Integrated on-grid and off-grid operation
  • Independent off-grid microgrid output
  • PV battery charging with up to 99.5% tracking efficiency
  • Scheduled AC reverse charging
  • LAN high-speed anti-backflow control
  • Smart Life remote monitoring and output adjustment
  • Full-isolation DAB dual full-bridge topology
  • IP67 enclosure with fanless natural cooling

Technical Data

Series Specifications

Rated Output Range400–4,000 W
MPPT Operating Voltage16–60 V DC
On-grid Starting Voltage>22 V DC
Off-grid Operating Voltage24–60 V DC
Nominal Output Voltage230 V AC (184–264 V AC)
Maximum Output Efficiency97%+
CEC Peak Efficiency98.5%
Maximum Tracking Efficiency99.5%
Frequency50 Hz / 60 Hz
On-grid THD<3%
Operating Temperature-40 to +65 °C
Enclosure RatingIP67
CommunicationWi-Fi
MonitoringSmart Life
IsolationFull isolation

Specifications are based on the supplied product literature. Confirm the final datasheet, grid standard and order configuration with sales before procurement.

Application Fit

Recommended Applications

  • Crystalline silicon PV systems
  • Balcony and residential solar installations
  • Battery-backed distributed energy systems
  • Projects requiring anti-backflow control

Procurement routes

Evaluate this platform in a buyer-specific workflow.

Move from technical data to a sample, OEM or project decision with the right compatibility checks and open-item list.

OEM & Distribution

OEM Microinverter Supply for Distributors

Start with the target market, PV module and sales configuration. TMG can then narrow the platform, define a sample BOM and identify the documents that still need market-specific confirmation before branding or volume production.

Open solution page →

Distributor System Package

Balcony Solar Kit OEM for Distributors

A distributor-ready kit is a controlled system, not a carton of unrelated parts. TMG can help align the module count, microinverter, cables, monitoring, packaging and destination-market documentation before sampling.

Open solution page →

Hybrid System Integrators

Hybrid Microinverters for Battery Backup Projects

APLV combines grid-tied conversion, an independent off-grid output, PV battery charging and scheduled AC reverse charging. A safe quotation still requires the battery interface, load profile, protection and operating sequence to be defined by the project team.

Open solution page →
